Steel sheet profile BPE 18 for walls

Our high-volume classic with a classic wooden panel look. Borga BPE 18 is used for covering walls on various buildings. Its optimised covering width makes it one of our most economical solutions. The asymmetrical shape with wide upper ribs and narrow bottom grooves gives the facade an ageless and classic appearance.

The profile can be installed either horizontally or vertically and is well suited for both small and large surfaces.

The steel core is passivated and painted with a primer and a top layer in polyester P30, P50, MAT or our premium Metallic Colofer® City Lights series.

Available thicknesses: 0.4 mm / 0.45 mm / 0.5 mm / 0.6 mm

Borga-BPE18-web2

PROFILE DATA BPE 18

Nominal thickness	t_nom	mm	0.5	0.6
Thickness for calculation	t_ber	mm	0.441	0.538
Mass	m	kg/m²	4.3	5.1
Yield strength	f_ty	N/mm²	250	250
Hight		mm	18	18
Cover width		mm	1080	1080
Min. length		mm	500	500
Max. length		mm	9000	10000

Support reaction, end support	R_d	kN/m	3.45	5.06
Support reaction, 50 mm support width	R_d	kN/m	11.80	16.98
Support reaction,100 mm support width	R_d	kN/m	15.50	22.12
Shear buckling capacity, flange	V_f	kN/m	15.9	28.8
Shear buckling capacity, rib	V_w	kN/m	63.7	77.7
Shear buckling capacity, global	L²V_gd	kN/m	19.7	26.6
Torque, positive pressure effect	M_d	kNm/m	0.434	0.578
Moment of inertia, positive pressure effect	I_def	mm⁴/mm	16.1	21.0
Moment, negative pressure effect	M_d	kNm/m	0.478	0.630
Moment of inertia negative pressure effect	I_def	mm⁴/mm	23.4	30.4

Walkability (c:c) calculated at a person weight of 100 kg, 2-bay, roof slope<14°, fastened	m	0.41	0.50
Walkability (c:c) calculated at a person weight of 100 kg, >2-fack, roof slope <14°, fastened	m	0.48	0.60
Walkability (c:c) calculated at a person weight of 100 kg, 2-fack, roof slope <14°, not fastened	m	0.33	0.41

Profile data is calculated according to the Eurocode.

Color variation

Standard Colors

White 9106

Light Grey 7035

Silver 9006

Graphite 0087

Black 9005

Beige 1015

Yellow 0453

Reseda Green 6011

Green 0510

Sky Blue 5015

Glowing Blue 5010

Brick Red 8004

Red 0302

Cherry Red 3009

Brown 8017

Galv

New York Silver-

Dubai White-

Moskau Grey-

New York Black-

Moskau Red-

Premium Colors

Dubai Blue-

Tokyo Violet
